EAP772 Indoor

$229.99 CAD
$229.99 CAD $229.99 CAD
Sale Sold out
In stock (21 units), ready to be shipped
  • BE11000 Tri-Band Wi-Fi 7 (5760 Mbps on 6 GHz + 4320 Mbps on 5 GHz + 574 Mbps on 2.4 GHz).†
  • A clear 6 GHz band brings cleaner and wider band resources.‡
  • 1× 2.5G Port unlocks the full potential of Wi-Fi 7.
  • 320 MHz bandwidth enables many more simultaneous transmissions.‡
  • Multi-Link Operation and Multi-RUs ensure the high performance of your network.‡
  • Advanced Functions: Centralized management, mesh, and AI roaming.△
Download Datasheet

Payment methods

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

View Product Details
  • HARDWARE FEATURES
  • Interface: 1× 2.5G Ethernet Port
  • Button: Reset
  • Power Supply: 802.3at PoE or 12V/2.5A DC
  • Max. Power Consumption: 25.44 W (PoE), 22.57 W (DC)
  • Dimensions (W x D x H): 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm)
  • Antenna: 2.4 GHz: 2× 4.0 dBi, 5 GHz: 2× 5.0 dBi, 6 GHz: 2× 5.0 dBi
  • Bluetooth: 1× 4.0 dBi, Bluetooth 5.2 (*Firmware update may be required)
  • Mounting: Ceiling / Wall Mounting (Kits Included)
  • WIRELESS FEATURES
  • Coverage: 140㎡ (1500 ft²)
  • Concurrent Clients: 380+**
  • Wireless Standards: IEEE 802.11 a/b/g/n/ac/ax/be
  • Frequency: 6 GHz, 5 GHz, 2.4 GHz
  • Signal Rate: 688 Mbps (2.4 GHz), 4324 Mbps (5 GHz), 5765 Mbps (6 GHz)
  • Wireless Functions: MLO, 4K-QAM, Seamless Roaming(802.11k/v/r), MU-MIMO, EHT320, Mesh, BSS Coloring, OFDMA, Load Balance, Band Steering, Beamforming, Airtime Fairness, Multiple SSIDs:24 (8 on each band), Wireless Schedule, Reboot Schedule, QoS(WMM), Rate Limit, Static IP/Dynamic IP, RADIUS Accounting, MAC Authentication
  • Wireless Security: Captive Portal Authentication, Access Control, Maximum MAC Filter: 4,000, Wireless Isolation Between Clients, VLAN, Rogue AP Detection, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
  • Transmission Power: < 25 dBm (2.4 GHz), < 25 dBm (5 GHz), < 23 dBm (6 GHz)
  • MANAGEMENT FEATURES
  • Omada App: Yes
  • Centralized Management: Omada Cloud-Based Controller, Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller
  • Cloud Access: Yes (Require OC300, OC200, Omada Software Controller, or Omada Cloud-Based Controller)
  • Email Alerts: Yes
  • LED ON/OFF Control: Yes
  • Management MAC Access Control: Yes
  • SNMP: v1, v2c, v3
  • System Logging Local/Remote Syslog: Yes
  • Web-based Management: Yes
  • OTHERS
  • Certification: CE, FCC, RoHS, IC
  • Package Content: EAP772, Installation Guide, Ceiling/Wall Mounting Kit (Note: Power Adapter NOT included)
  • Environment: Operating Temperature 0–40 °C (32–104 °F), Storage Temperature -40–70 °C (-40–158 °F), Operating Humidity 10–90% non-condensing, Storage Humidity 5–90% non-condensing
