RP-PCT8MD

Video & Audio Specifications

• Image Sensor: 1/2.65" CMOS Sensor
• Resolution: 5120 × 1552 (8 Megapixels) @ 25 FPS
• Lens: 2.8mm Fixed Lens, F1.6
• Zoom: N/A
• Video Compression: H.265 / H.264
• Field of View: Horizontal: 180°, Vertical: 57°
• Day & Night: IR-Cut Filter with Auto Switching
• Infrared Night Vision: Up to 30 Meters (100 ft), 6 × 3W / 850nm IR LEDs
• Color Night Vision: 6 Spotlights, 3.5W, 4000K, 400 Lumens
• Frame Rate: Main Stream: 2–25 FPS (Default: 25 FPS), Sub Stream: 4–20 FPS (Default: 20 FPS)
• Bit Rate: Main Stream: 3072–10240 Kbps (Default: 8192 Kbps), Sub Stream: 256–2048 Kbps (Default: 1024 Kbps)
• Audio: Two-Way Audio
• PoE: IEEE 802.3af, 48V Active
• DC Power: DC 12V / 2A, Power Consumption < 12W
• Power Port: DC Power Port
• Ethernet Port: 1 × 10/100 Mbps RJ45 Port
• Storage: MicroSD Card Slot (Supports up to 512GB), Reolink NVR, FTP
• Reset Button: Yes
• Alarm In/Out: N/A
• Audio In/Out: Built-in Microphone & Speaker
• Supported Browsers: Microsoft Edge, Chrome, Firefox, Safari
• Supported Operating Systems: Windows, macOS, iOS, Android
• Protocols & Standards: HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P, ONVIF
• Maximum User Access: 20 Users (1 Admin + 19 Users), Supports up to 12 Simultaneous Streams (2 Main Streams & 10 Sub Streams)
• Smart Alarm: Motion Detection, Human Detection, Vehicle Detection, Animal Detection
• Perimeter Protection: Line Crossing Alert, Zone Intrusion Alert, Zone Loitering Alert
• Smart Event Detection: Object Removal (Beta), Forgotten Object (Beta)
• Recording Modes: Motion-Triggered Recording (Default), Scheduled Recording, 24/7 Continuous Recording
• Smart Home Compatibility: Google Assistant
• AI Video Search: Yes
• AI ISP: No
• HDR: No
• Time Lapse: Yes
• Motion Tracking: N/A
• Operating Temperature: -30°C to +55°C
• Operating Humidity: 10%–90%
• Weatherproof Rating: IP67
• Dimensions: 132 × 131 × 72 mm
• Weight: 775 g (Without Accessories)
