MikroTik Chateau 5G ax

$753.59 CAD
$753.59 CAD
Sale Sold out
Shipping calculated at checkout.
Only 1 units left

Mobile internet has never been faster! Generation 6 version of Chateau 5G. Much faster wireless, improved CPU, and now – with 2.5 Gigabit Ethernet!

The next obvious step in the Chateau series was perfecting the wireless capabilities. With the Generation6 802.11ax wireless standard and Wave 2 support, Chateau 5G ax can deliver unprecedented speed. If we compare it to the previous generation, we’re looking at up to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum! We’ve made massive improvements to the wireless radio and antennas. Chateau 5G ax supports MIMO 4×4 on 5G and LTE. There are 6 built-in LTE/5G antennas. One pair of external antennas provides even better wireless network coverage in the largest homes, and the other – improved LTE/5G connectivity.

With speeds like that, the ports also had to rise to the occasion. We kept four Gigabit Ethernet ports and added a 2.5 Gigabit Ethernet port on top. And let’s not forget the USB which can be handy for storage purposes.

The modern quad-core CPU running at 1.8 GHz combined with a solid GB of RAM packs a hefty punch when it comes to heavy operations like complex firewall rules, IPsec hardware encryption, using more threads or experimenting with advanced RouterOS features. And with the addition of WPA3 advanced encryption support, you’re safer than ever before.


Click here to download the Datasheet.

Payment methods

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

  • Vendor:

    MikroTik

View Product Details
  • Product code: S53UG+M-5HaxD2HaxD-TC&RG502Q-EA
  • Architecture: ARM 64bit
  • CPU: IPQ-6010 (4 cores, auto 864-1800 MHz, 4 threads)
  • Switch chip model: IPQ-6010
  • Dimensions: 240 x 156 x 44 mm
  • RouterOS license: 4
  • Operating System: RouterOS v7
  • RAM: 1 GB
  • Storage: 128 MB NAND
  • MTBF: Approximately 200,000 hours at 25°C
  • Tested ambient temperature: -40°C to 70°C
  • Powering:

    Number of DC inputs: 1 (DC jack)
    DC jack input Voltage: 12-28 V
    Max power consumption: 19 W (16 W without attachments)
    Cooling type: Passive

  • Mobile:

    3G Category: R8 (42.2 Mbps Downlink, 5.76 Mbps Uplink)
    3G bands: 1, 3, 5, 6, 8, 19
    LTE Category: 20 (2.0 Gbps Downlink, 200 Mbps Uplink)
    MIMO: DL 4x4, UL 1x1
    LTE FDD bands: 1,3,5,7,8,18,19,20,26,28,32
    LTE TDD bands: 34,38,39,40,41,42,43
    5G NSA FDD bands: 1,3,5,7,8,20,28
    5G NSA TDD bands: 38,40,41,77,78,79
    5G SA FDD bands: 1,3,5,7,8,20,28
    5G SA TDD bands: 38,40,41,77,78,79
    TAC: 86073604

  • Wireless specifications:

    2.4 GHz: 574 Mbit/s, 2 chains, 802.11b/g/n/ax, Antenna gain 3 dBi, Chip QCN-5022 (Wi-Fi 6)
    5 GHz: 1200 Mbit/s, 2 chains, 802.11a/n/ac/ax, Antenna gain 6 dBi, Chip QCN-5052 (Wi-Fi 6)
    WiFi speed: AX1800

  • Ethernet:

    10/100/1000 Ethernet ports: 4
    2.5G Ethernet port: 1

  • Peripherals:

    SIM slots: 1 (Micro SIM)
    USB ports: 1 (Type A, Power Reset, Max 1A)
    M.2 slots: 1

  • Other:

    PCB temperature monitor: Yes
    Voltage monitor: Yes
    Mode button: Yes

  • Certification & Approvals: CE, EAC, ROHS
  • IP Rating: IP20
The MikroTik Chateau 5G ax is a high-performance wireless router designed for users who need fast 5G mobile broadband together with modern WiFi 6 connectivity. It is suitable for homes, offices, remote sites, and backup internet setups where reliable cellular access is important. By combining 5G connectivity, WiFi 6, and Gigabit Ethernet, the Chateau 5G ax provides flexible options for both wireless and wired devices. It can support everyday business applications, video conferencing, cloud services, streaming, and other bandwidth-intensive tasks while maintaining a compact all-in-one design. Running MikroTik RouterOS, the Chateau 5G ax also offers advanced routing, firewall, VPN, traffic management, and network configuration capabilities. This makes it a practical option for users who want both high-speed mobile internet and greater control over their network.

FAQs : MikroTik Chateau 5G ax

The Chateau 5G ax is a WiFi 6 router with integrated 5G mobile connectivity, designed for fast and flexible internet access in home and professional environments.
Yes. It supports WiFi 6, helping improve wireless efficiency, performance, and device capacity for compatible clients.
It is suitable for homes, offices, branch locations, remote sites, and backup internet deployments that need both 5G and wired network connectivity.
You can buy the MikroTik Chateau 5G ax from JRS Global Technologies Canada through jrsglcanada.com for MikroTik networking products and solutions.
