Chateau 5G ax

Regular price $699.90 CAD
Sale price $699.90 CAD Regular price $833.00 CAD
Sale Sold out
Only 4 units left

Mobile internet has never been faster! Generation 6 version of Chateau 5G. Much faster wireless, improved CPU, and now – with 2.5 Gigabit Ethernet!

The next obvious step in the Chateau series was perfecting the wireless capabilities. With the Generation6 802.11ax wireless standard and Wave 2 support, Chateau 5G ax can deliver unprecedented speed. If we compare it to the previous generation, we’re looking at up to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum! We’ve made massive improvements to the wireless radio and antennas. Chateau 5G ax supports MIMO 4×4 on 5G and LTE. There are 6 built-in LTE/5G antennas. One pair of external antennas provides even better wireless network coverage in the largest homes, and the other – improved LTE/5G connectivity.

With speeds like that, the ports also had to rise to the occasion. We kept four Gigabit Ethernet ports and added a 2.5 Gigabit Ethernet port on top. And let’s not forget the USB which can be handy for storage purposes.

The modern quad-core CPU running at 1.8 GHz combined with a solid GB of RAM packs a hefty punch when it comes to heavy operations like complex firewall rules, IPsec hardware encryption, using more threads or experimenting with advanced RouterOS features. And with the addition of WPA3 advanced encryption support, you’re safer than ever before.


Click here to download the Datasheet.

Payment methods

Payment methods
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

View Product Details
  • Product code: S53UG+M-5HaxD2HaxD-TC&RG502Q-EA
  • Architecture: ARM 64bit
  • CPU: IPQ-6010 (4 cores, auto 864-1800 MHz, 4 threads)
  • Switch chip model: IPQ-6010
  • Dimensions: 240 x 156 x 44 mm
  • RouterOS license: 4
  • Operating System: RouterOS v7
  • RAM: 1 GB
  • Storage: 128 MB NAND
  • MTBF: Approximately 200,000 hours at 25°C
  • Tested ambient temperature: -40°C to 70°C
  • Powering:

    Number of DC inputs: 1 (DC jack)
    DC jack input Voltage: 12-28 V
    Max power consumption: 19 W (16 W without attachments)
    Cooling type: Passive

  • Mobile:

    3G Category: R8 (42.2 Mbps Downlink, 5.76 Mbps Uplink)
    3G bands: 1, 3, 5, 6, 8, 19
    LTE Category: 20 (2.0 Gbps Downlink, 200 Mbps Uplink)
    MIMO: DL 4x4, UL 1x1
    LTE FDD bands: 1,3,5,7,8,18,19,20,26,28,32
    LTE TDD bands: 34,38,39,40,41,42,43
    5G NSA FDD bands: 1,3,5,7,8,20,28
    5G NSA TDD bands: 38,40,41,77,78,79
    5G SA FDD bands: 1,3,5,7,8,20,28
    5G SA TDD bands: 38,40,41,77,78,79
    TAC: 86073604

  • Wireless specifications:

    2.4 GHz: 574 Mbit/s, 2 chains, 802.11b/g/n/ax, Antenna gain 3 dBi, Chip QCN-5022 (Wi-Fi 6)
    5 GHz: 1200 Mbit/s, 2 chains, 802.11a/n/ac/ax, Antenna gain 6 dBi, Chip QCN-5052 (Wi-Fi 6)
    WiFi speed: AX1800

  • Ethernet:

    10/100/1000 Ethernet ports: 4
    2.5G Ethernet port: 1

  • Peripherals:

    SIM slots: 1 (Micro SIM)
    USB ports: 1 (Type A, Power Reset, Max 1A)
    M.2 slots: 1

  • Other:

    PCB temperature monitor: Yes
    Voltage monitor: Yes
    Mode button: Yes

  • Certification & Approvals: CE, EAC, ROHS
  • IP Rating: IP20
