TP-Link SG3452P

SKU: TP-SG3452P-Open

$829.98 CAD
$829.98 CAD
Sale Sold out
Shipping calculated at checkout.
Only 6 units left

JetStream 52-Port Gigabit L2+ Managed Switch with 48-Port PoE+

Features & Compatibility

  • 384 W PoE Budget: 48× 802.3at/af-compliant PoE+ ports with a total power supply of 384 W*.
  • Full Gigabit Ports: 48× gigabit RJ45 ports and 4× gigabit SFP Slots provide high-speed connections.
  • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
  • Static Routing: Helps route internal traffic for more efficient use of network resources.
  • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
  • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
  • Standalone Management: Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities.

Click here to download the Datasheet.

Payment methods

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

  • Vendor:

    Tp-link

View Product Details

HARDWARE FEATURES

  • Interface:

    48× 10/100/1000 Mbps PoE+ RJ45 Ports
    4× Gigabit SFP Slots
    1× RJ45 Console Port
    1× Micro-USB Console Port

  • Fan Quantity: 3
  • Physical Security Lock: √
  • Power Supply: 100-240 V AC~50/60 Hz
  • PoE Ports (RJ45):

    Standard: 802.3at/af compliant
    PoE+ Ports: 48 Ports (up to 30 W PoE Output per Port)
    PoE Power Budget: 384 W*

  • Dimensions (W x D x H): 17.3×13.0×1.7 in (440×330×44 mm)
  • Mounting: Rack Mountable
  • Max. Power Consumption: 464.2 W (110 V/60 Hz) (with 384 W PD connected)
  • Max. Heat Dissipation: 1584.08 BTU/hr (110 V/60 Hz) (with 384 W PD connected)

PERFORMANCE

  • Packet Buffer Memory: 12 Mbit
  • Jumbo Frame: 9 KB
  • Switching Capacity: 104 Gbps
  • Packet Forwarding Rate: 77.38 Mpps
  • MAC Address Table: 16 K

SOFTWARE FEATURES

  • Quality of Service:

    8 priority queues
    802.1p CoS/DSCP priority
    Queue scheduling: SP (Strict Priority), WRR (Weighted Round Robin), SP+WRR
    Bandwidth Control: Port/Flow based Rating Limiting
    Smoother Performance
    Action for Flows: QoS remark (802.1P Remark, DSCP Remark)

  • L2 and L2+ Features:

    32 IP Interfaces: Support IPv4/IPv6 Interface
    Static Routing: 48 IPv4/IPv6 Static Routes
    Static ARP: 128 static entries
    316 ARP Entries
    Proxy ARP
    Gratuitous ARP
    DHCP Server
    DHCP Relay: DHCP Interface Relay, DHCP VLAN Relay, DHCP L2 Relay
    Link Aggregation
    Spanning Tree Protocol
    Loopback Detection
    802.3x Flow Control
    Mirroring
    Device Link Detect Protocol (DLDP)

  • L2 Multicast:

    Supports 511 (IPv4, IPv6) IGMP groups
    IGMP Snooping
    IGMP Authentication
    Multicast VLAN Registration (MVR)
    MLD Snooping
    Multicast Filtering: 256 profiles and 16 entries per profile

  • Advanced Features: Automatic Device Discovery†, Batch Configuration†, Batch Firmware Upgrading†, Intelligent Network Monitoring†, Abnormal Event Warnings†, Unified Configuration†, Reboot Schedule†
  • ISP Features:

    L2PT (Layer 2 Protocol Tunneling)
    Device Link Detect Protocol (DLDP)
    PPPoE ID Insertion
    ERPS
    802.3ah Ethernet Link OAM

  • VLAN:

    VLAN Group: Max 4K VLAN Groups
    802.1q Tagged VLAN
    MAC VLAN: 48 Entries
    Protocol VLAN: Protocol Template 16, Protocol VLAN 16
    GVRP
    VLAN VPN (QinQ): Port-Based QinQ; Selective QinQ
    Voice VLAN

  • Access Control List:

    Time-based ACL
    MAC ACL: Source MAC, Destination MAC, VLAN ID, User Priority, Ether Type
    IP ACL: Source IP, Destination IP, Fragment, IP Protocol, TCP Flag, TCP/UDP Port, DSCP/IP TOS, User Priority
    Combined ACL
    Packet Content ACL
    IPv6 ACL
    Policy: Mirroring, Redirect, Rate Limit, QoS Remark
    ACL apply to Port/VLAN

  • Security:

    IP-MAC-Port Binding: 512 Entries, DHCP Snooping, ARP Inspection, IPv4 Source Guard: 100 Entries
    IPv6-MAC-Port Binding: 512 Entries, DHCPv6 Snooping, ND Detection, ND Snooping, IPv6 Source Guard: 100 Entries
    DoS Defend
    DHCP Filter
    Static/Dynamic Port Security: Up to 64 MAC per port
    Broadcast/Multicast/Unicast Storm Control: kbps/ratio/pps control mode
    802.1X: Port-based authentication, MAC-based authentication, VLAN Assignment, MAB, Guest VLAN, Radius support
    AAA (including TACACS+)
    Port Isolation
    Secure web management (HTTPS SSLv3/TLS 1.2)
    Secure CLI management (SSHv1/SSHv2)
    IP/Port/MAC-based access control

  • IPv6:

    IPv6 Dual IPv4/IPv6
    MLD Snooping, IPv6 ACL, IPv6 Interface, Static IPv6 Routing
    IPv6 neighbor discovery (ND), Path MTU discovery
    ICMPv6, TCPv6/UDPv6
    IPv6 applications: DHCPv6 Client, Ping6, Tracert6, Telnet(v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, HTTP/HTTPS, IPv6 TFTP

  • MIBs:

    MIB II (RFC1213)
    Bridge MIB (RFC1493)
    P/Q-Bridge MIB (RFC2674)
    Radius Accounting Client MIB (RFC2620)
    Radius Authentication Client MIB (RFC2618)
    Remote Ping, Traceroute MIB (RFC2925)
    Support TP-Link private MIBs
    RMON MIB(RFC1757, rmon 1,2,3,9)

MANAGEMENT FEATURES

  • Omada App: Yes. Requires Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller
  • Centralized Management:

    Omada Cloud-Based Controller
    Omada Hardware Controller
    Omada Software Controller

  • Cloud Access: Yes. Requires Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller
  • Zero-Touch Provisioning: Yes. Requires Omada Cloud-Based Controller
  • Management Features:

    Web-based GUI
    CLI through console port, telnet
    SNMPv1/v2c/v3: Trap/Inform, RMON (1,2,3,9 groups)
    SDM Template
    DHCP/BOOTP Client
    802.1ab LLDP/LLDP-MED
    DHCP AutoInstall
    Dual Image, Dual Configuration
    CPU Monitoring
    Cable Diagnostics
    EEE
    Password Recovery
    SNTP
    System Log

OTHERS

  • Certification: CE, FCC, RoHS
  • Package Content:

    SG3452P Switch
    Power Cord
    Quick Installation Guide
    Rackmount Kit
    Rubber Feet

  • System Requirements: Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX®, Linux
  • Environment:

    Operating Temperature: 0–40 ℃ (32–104 ℉)
    Storage Temperature: -40–70 ℃ (-40–158 ℉)
    Operating Humidity: 10–90% RH non-condensing
    Storage Humidity: 5–90% RH non-condensing

The TP-Link Omada SG3452P is a high-capacity L2+ managed switch designed for business networks that need extensive wired connectivity, centralized PoE power, and flexible fiber uplinks. It features 48 Gigabit PoE+ RJ45 ports and 4 Gigabit SFP slots, giving organizations plenty of capacity for access points, IP cameras, VoIP phones, computers, and other network devices. With a 384W total PoE budget and support for IEEE 802.3af/at, the SG3452P can power compatible devices directly through Ethernet cabling. This helps reduce separate power requirements and makes deployment cleaner in offices, hotels, schools, surveillance environments, campuses, and other professional installations. The switch also supports features such as static routing, VLAN, ACL, QoS, IGMP Snooping, and Omada centralized cloud management. These capabilities make it suitable for organizations that want better control over network traffic, segmentation, security, and expansion from a unified management platform.

FAQs : TP-Link SG3452P

The SG3452P is a 52-port Gigabit L2+ managed switch with 48 PoE+ Ethernet ports and 4 Gigabit SFP slots, designed for medium to large professional networks.
It provides 48 Gigabit PoE+ ports, with support for up to 30W per compatible port and a total PoE budget of 384W.
The SFP slots provide fiber uplink options for connecting other switches, extending network links, and integrating the SG3452P into larger network infrastructures.
You can buy the TP-Link SG3452P from JRS Global Technologies Canada through jrsglcanada.com for TP-Link business networking products and solutions.
