RLN-VDB2K03W

Video & Audio

Image Sensor 1/3" CMOS sensor

Resolution 2048 × 2048 (4 megapixels) @ 15fps

Lens f=1.2mm, F=1.8

Video Compression H.264 / H.265

Field of View
Diagonal: 180°
Horizontal: 150°
Vertical: 150°
Audio Two-way audio

Power Requirements

Battery Up to 300 days of battery life (Based on 5-min recordings per day)

Hardwire
Battery Power Mode: 8-24V AC, 24V DC
Wired Power Mode: 16-24V AC, 24V DC

Interface

Power Port USB Type-C port

microSD Card Slot Supports Max. 512GB microSD card

Reset Button Yes

Audio In/Out Built-in 2 microphones and a speaker

Wi-Fi

Wireless Standard IEEE 802.11 a/b/g/n

Operating Frequency 2.4 / 5 GHz

Wireless Security WPA / WPA2

Software

OS Supported
PC: Windows, Mac OS
Smartphone: iOS, Android
Protocols & Standards
SSL, TCP/IP, UDP, SMTP, NTP, P2P, ONVIF*, RTSP*
(*Requires App 4.62.1+)

Other Features

Smart Alarm Motion detection; person / vehicle / animal detection; package detection; visitor detection

Recording Modes
Battery mode: Motion-triggered recording
Wired mode: 24/7 recording & pre-recording
Smart Home Compatibility
Google Assistant; Alexa; IFTTT; Home Assistant*
(*Direct connection supported; no Home Hub required.)
Rich Notification Yes

Quick Replies Yes

Video Call Yes

Tamper Alert Yes

Cloud Storage Supports Reolink Cloud (available in selected countries)

Working Environment

Operating Temperature -10°C to 55°C (14°F to 131°F)

Operating Humidity 10% to 90%

Weatherproof IP65

Mechanical

Dimensions 160.0 x 48.0 x 29.5 mm

Weight 231g
