64-Channel NVR with 80TB Storage Capacity

  • 4X 20TB HDD Capacity
  • 64 Channels
  • On-Device AI Video Search
  • Disk Group Mode
  • Video File Encryption
  • 8X Alarm In / 4X Alarm Out
  • Intelligent H.265+
  • Heat Mapping Technology


Payment methods

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

  • Vendor:

    Reolink

View Product Details
  • Video/Audio Input
  • IP Video Input: Up to 64 IP Cameras (Max. 64 wired cameras), up to 16 MP resolution
  • Device Compatible: All Reolink Cameras (except for 4G Cameras)
  • Audio Input: 1 audio in channel, RCA; via cameras with mic
  • Incoming Bandwidth: 768 Mbps
  • Outgoing Bandwidth: 768 Mbps
  • Video/Audio Output
  • Video Output: 2 HDMI
  • Display Resolution: HDMI: 3840x2160, 2560x1440, 1920x1080, 1280x1024, 1280x720, 1024x768
  • Audio Output: 1 audio out channel, RCA
  • Decoding
  • Video Compression: Intelligent H.265+, H.265, H.264
  • Live View / Playback Resolution: 7680x2160, 4608x1728, 4512x2512, 4096x3072, 3840x2160, 2560x2560, 2560x1920, 2560x1440, 2048x1536, 2304x1296, 1080P, 720P
  • Capability: 64x896x512 @20fps
  • Capability: 8x4MP @20fps
  • Capability: 6x5MP @20fps
  • Capability: 4x8MP @20fps
  • Capability: 2x12MP @20fps
  • Capability: 2x16MP @20fps
  • Synchronous Playback: Up to 4-channel playback (up to 8MP) or 1-channel playback (above 8MP)
  • Storage
  • SATA: 4 SATA interfaces
  • Record Channels: 64 channels
  • External HDD Slot: N/A
  • Capacity: Up to 80TB (up to 20TB capacity for each HDD)
  • File Encryption: Yes
  • MicroSD Card Slot: N/A
  • External Interface
  • USB Interface: 2 x USB 2.0 + 1 x USB 3.0
  • Network Interface: 8 x RJ-45, 10/100/1000 Mbps self-adaptive (for switches)
  • Network Interface: 1 x RJ-45, 10/100/1000 Mbps self-adaptive (for LAN/WAN)
  • Alarm In/Out: In: 8 channels; Out: 4 channels
  • PoE
  • Max. Power Per Port: N/A
  • Supported Standard: N/A
  • Network
  • Network Protocols: HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, RTMP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
  • Browsers Supported: Edge, Firefox, Chrome, Safari
  • OS Supported: PC: Windows, Mac OS; Smartphone: iOS, Android
  • User Access: 20 users (1 admin account and 19 user accounts); supports up to 12 simultaneous video streams (10 substreams and 2 mainstreams)
  • Other Features
  • AI Video Search: Yes
  • Heat Map: Yes
  • People Counting & Zone Crowd Monitoring: Yes (camera support required)
  • Perimeter Protection: Yes (camera support required)
  • Smart Event Detection: Forgotten Object (camera support required)
  • Smart Event Detection: Object Removal (camera support required)
  • General
  • Power Supply: 100-240 VAC, 50/60Hz, 1.5A
  • Power Consumption: <10W (without HDD & PoE)
  • Working Environment: Temperature: -10°C to +45°C (14°F to 113°F)
  • Working Environment: Humidity: 10% to 90%
  • Dimensions: 440 x 314.3 x 44 mm
  • Weight: 2.88 kg (without HDD)
