RLN-E SERIES E540

Specifications

Video & Audio

Image Sensor 1/2.7" CMOS Sensor

Video Resolution2560 × 1920 (5 Megapixels) @ 20 FPS Lensf = 2.8–8 mm, Max. F1.6 Video CompressionH.264 Field of View
Horizontal: 90°–50°
Vertical: 53°–30°
Zoom Mode 3X Optical Zoom

Color Night Vision With Spotlights: 4 pcs / 3.3W / 6500K Infrared Night VisionUp to 12 Meters (40 ft); LED: 10 pcs / 850nm (Auto-switching with IR-cut filter) Frame Rate
Main Stream: 2–20 FPS (Default: 20 FPS)
Sub Stream: 4–15 FPS (Default: 10 FPS)
Code Rate
Main Stream: 2048–5120 Kbps (Default: 3072 Kbps)
Sub Stream: 64–512 Kbps (Default: 256 Kbps)
AudioTwo-Way Audio

Power Requirements

DC PowerDC 12.0V ⎓ 1A

Interface

Power DC Power Port

Ethernet One 10M/100Mbps RJ45 Port

microSD Card Slot Supports microSD Cards up to 512GB

Reset Button Yes

Audio In/OutBuilt-in Microphone and Speaker

Software Features

Browsers Supported Edge, Chrome, Firefox, Safari

Operating Systems Supported PC: Windows, Mac OS; Smartphone: iOS, Android

Protocols & Standards HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P

Maximum User Access
Maximum 20 Users (1 Admin & 19 Users)
Maximum 12 Simultaneous Streams (2 Main & 10 Substreams)
Recording Modes Motion-Triggered Recording (Default), Scheduled Recording, 24/7 Recording

Other Features

Smart Alarm Motion Detection, Person Detection, Vehicle Detection, Animal Detection

Time Lapse Yes

Smart Home Compatibility Google Assistant

Pan & Tilt

PT Angle (Max.) Pan: 355°, Tilt: 50°

Preset Supports 1 Guard Position & Up to 64 Preset Positions

Power-Off Memory Function Yes

Auto Tracking Yes

Wi-Fi

Wireless Standard IEEE 802.11 a/ac/b/g/n

Operating Frequency 2.4GHz / 5GHz

Wireless Security WPA / WPA2

Working Environment

Operating Temperature -10°C to +55°C (14°F to 131°F)

Operating Humidity 20%–85%

Weatherproof Rating IP65

Size & Weight

Dimensions Φ90 × 120 mm

Weight 458 g
