RLN-ALTAS SERIES B660 WITH SOLAR PANEL 3

Video & Audio

Image Sensor1/1.8" CMOS Sensor Video Resolution3840 × 2160 (8 Megapixels) @ 15fps Lensf=4mm, Fixed Video CompressionH.264 / H.265Field of View

• Diagonal: 110°
• Horizontal: 90°
• Vertical: 50°

Infrared Night VisionNo Color Night VisionYes Frame RateMain/Sub Stream: 10fps–15fps AudioTwo-way Audio

Power

Battery3.6V 20000mAh rechargeable battery (72Wh power capacity). Battery life varies based on settings, usage, and temperature. SolarReolink Solar Panel 2 (6W)

Pan & Tilt

PT Angle (Max.)Pan: 355°, Tilt: 90° Auto TrackingYes

Bluetooth Standard

Bluetooth VersionBluetooth 5.0

Interface

Power PortUSB Type-C port (Supports USB-A to USB-C cable only) SD Card SlotSupports microSD cards up to 512GB Reset ButtonYes Audio In/OutBuilt-in microphone and speaker

Wi-Fi

Wireless StandardIEEE 802.11 a/b/g/n/ac/ax Operating Frequency2.4GHz / 5GHz Wireless SecurityWPA / WPA2 / WPA3

Software

OS SupportedPC: Windows, Mac OS; Smartphone: iOS, Android Protocols & StandardsSSL, TCP/IP, UDP, UPnP, SMTP, NTP, P2P User AccessMaximum 12 simultaneous streams (2 main and 10 sub streams)

Other Features

Smart AlarmPIR detection; motion detection; person detection; vehicle detection; animal detection PIR Detecting DistanceAdjustable, up to 10m (33ft) PIR Detecting Angle100° horizontal Recording ModesMotion recording; scheduled recording; 24/4 recording Time LapseYes Smart Home CompatibilityGoogle Assistant Home Hub CompatibilityYes Cloud StorageSupports Reolink Cloud (available in selected countries)

Working Environment

Operating Temperature-10°C to +55°C (14°F to 131°F) Operating Humidity20%–85% WeatherproofIP65

Mechanical

Dimensions178 × 151 × 102 mm Weight (Without Bracket)853g
