cAP XL ac(RBcAPGi-5acD2nD-XL-US)
Couldn't load pickup availability
The ceiling AP on steroids! Our bestseller cAP is back – juiced up and stronger than ever. Compared to the previous cAP models, the improved high-gain antenna increases the covered area by up to 100%!
The dual-band, dual-chain 2.4 and 5 GHz wireless radio provides a strong coverage in 360 degrees around it, so you don’t have to worry about the placement of the device so much. Putting it on the ceiling eliminates many signal absorption problems, such as the signal being blocked by large TV sets, metal cubicle walls in open space offices, etc.
Even though the radio supports repeater mode, the two Gigabit Ethernet ports give you the ability to extend your network with cables, even if PoE power is required: the cAP XL ac supports 802.3af/at PoE input on the first port and passive PoE output (up to 57V) on the second port.
Download DatasheetPayment methods
Payment methods-
Vendor:
MikroTik
- Tags: Cap xl ac, Ceiling mount dual-band access points, Mikrotik, Wireless access points

Specifications
- Product Code: RBcAPGi-5acD2nD-XL
System
- Architecture: ARM 32-bit
- CPU: IPQ-4018 (Quad-core, 488–896 MHz)
- Threads: 4
- Switch Chip: IPQ-4018
- Operating System: RouterOS
- License Level: 4
Memory & Storage
- RAM: 128 MB
- Storage: 16 MB FLASH
Physical
- Dimensions: 191 × 42 mm
- MTBF: ~100,000 hours at 25°C
- Operating Temperature: -40°C to 70°C
- Cooling: Passive
Wireless
- Wi-Fi Speed: AC1200
- 2.4 GHz: 300 Mbps, 2 chains, 802.11b/g/n (Wi-Fi 4), 6 dBi antenna
- 5 GHz: 867 Mbps, 2 chains, 802.11a/n/ac (Wi-Fi 5), 5.5 dBi antenna
Networking
- Ethernet Ports: 2 × Gigabit (10/100/1000)
- PoE-Out Port: 1 × Gigabit (Ether2)
Power
- Input: PoE-IN (802.3af/at)
- Voltage Range: 18–57 V
- Max Power Consumption: 24 W
- Without Attachments: 11 W
PoE-Out
- Type: Passive PoE (up to 57V)
- Port: Ether2
- Max Current: 500 mA
Other Features
- Mode Button: Yes
Certifications
- Certifications: CE, FCC, IC, EAC, ROHS
