Our most cost-effective Wi-Fi 6 access point yet. Triple-chain 5 GHz radio (up to 900 Mbit/s throughput), dual-band Wi-Fi 6, 5x Gigabit Ethernet ports, and a 2.5G SFP. Powered by a dual-core ARM CPU, with PoE-in/PoE-out flexibility, a standard DC jack, USB, and a sturdy high-end enclosure that can be mounted on the wall.
Triple-chain 5 GHz:
the key to stable, gigabit-class Wi-Fi
The new hAP ax S features a triple-chain 5 GHz radio that achieves real-world throughput of around 800–900 Mbit/s. That means smooth streaming, faster downloads, and stable performance across multiple devices – even in crowded environments.
It’s also perfect as a dedicated Wi-Fi 6 VR streaming access point for PC VR headsets, offering higher resolution and lower latency without the cables. Unlike single-purpose “gaming” access points, the hAP ax S gives you the full performance, flexibility, and future-proofing of RouterOS v7!
- Product codeE62iUGS-2axD5axT
- Suggested price$79.00
- ArchitectureARM 32bit
- CPUEN7562CT
- CPU core count2
- CPU nominal frequency950 MHz
- CPU Threads count2
- Switch chip modelEN7523
- RouterOS license4
- Operating SystemRouterOS v7
- Size of RAM512 MB
- Storage size128 MB
- Storage typeNAND
- MTBFApproximately 100'000 hours at 25C
- Tested ambient temperature-40°C to 70°C
- Wireless 2.4 GHz Max data rate574 Mbit/s
- Wireless 2.4 GHz Number of chains2
- Wireless 2.4 GHz standards802.11b/g/n/ax
- Antenna gain dBi for 2.4 GHz5.5
- Wireless 2.4 GHz chip modelMT7916
- Wireless 2.4 GHz generationWi-Fi 6
- Wireless 5 GHz Max data rate1800 Mbit/s
- Wireless 5 GHz Number of chains3
- Wireless 5 GHz standards802.11a/n/ac/ax
- Antenna gain dBi for 5 GHz8.07
- Wireless 5 GHz chip modelMT7976
- Wireless 5 GHz generationWi-Fi 6
- WiFi speedAX2400
- 10/100/1000 Ethernet ports5
- Number of 1G Ethernet ports with PoE-out1
- SFP ports1 (2.5G supported)
- Number of USB ports1
- USB Power ResetYes
- USB slot typeUSB type A
- Max USB current (A)1
- Number of DC inputs2 (DC jack, PoE-IN)
- DC jack input Voltage12-28 V
- Max power consumption34 W
- Max power consumption without attachments11 W
- PoE inPassive PoE
- Cooling typePassive
- PoE in input Voltage18-28 V
- PoE-out portsEther5
- PoE outPassive PoE
- Low voltage PoE-Out current limit0.6 A
- Max total out (A)0.6 A
- Total output current0.6
- Total output power16.8
