TP-Link Omada EAP653 AX3000 Dual-Band WiFi 6 Access Point

SKU: TP-EAP653

$115.99 CAD
$115.99 CAD $119.99 CAD
Sale Sold out
Shipping calculated at checkout.
Only 21 units left

TP-Link EAP653

AX3000 Ceiling Mount WiFi 6 Access Point

Lightning-Fast AX3000 WiFi 6 Speeds New-era business WiFi 6 with speeds up to 2976 Mbps brings more than twice the speed of WiFi 5.† Every application feels more fluid with drastically improved WiFi speeds.

Features:

  • Ultra-Fast WiFi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz totals 2976 Mbps WiFi speeds.†
  • High-Efficiency WiFi 6: More connected devices can enjoy faster speeds.
  • Centralized Cloud Management: Omada SDN integration manages the whole network locally or from the cloud via web UI or Omada app.
  • 160 MHz Channel: Double the data at peak transmission times on a single stream with HE160.‡
  • Seamless Roaming: Video streams and voice calls are unaffected as users move between locations.§
  • Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.§
  • PoE+ Powered: Supports both 802.3at PoE+ and DC (DC adapter sold separately) power supply for flexible installations.
  • Ultra-Slim Design: Φ160 mm × 33.6 mm elegant design brings more agility.

Click here to download the Datasheet.

Payment methods

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

  • Vendor:

    Tp-link

View Product Details

Hardware Features

  • Interface: 1× Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
  • Button: Reset
  • Power Supply:

    802.3at PoE
    12V DC (EU Version: 12V / 1.0A DC, US Version: 12V / 1.5A DC)
    Note: DC adapter is not included in the package and sold separately

  • Power Consumption:

    EU: 13.5 W
    US: 14.7 W

  • Dimensions (W × D × H): 6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm)
  • Antenna Type: Internal Omni

    2.4 GHz: 2× 4 dBi
    5 GHz: 2× 5 dBi

  • Mounting:

    Ceiling / Wall Mounting (Kits included)
    Junction Box Mounting

Wireless Features

  • Wireless Standards: IEEE 802.11ax/ac/n/g/b/a
  • Frequency: 2.4 GHz and 5 GHz
  • Signal Rate:

    5 GHz: Up to 2402 Mbps†
    2.4 GHz: Up to 574 Mbps†

  • Wireless Functions:

    1024-QAM
    4× Longer OFDM Symbol
    OFDMA
    Multiple SSIDs (Up to 16, 8 per band)
    Enable/Disable Wireless Radio
    Automatic Channel Assignment
    Transmit Power Control (Adjust dBm)
    QoS (WMM)
    MU-MIMO
    HE160 (160 MHz Bandwidth)‡
    Seamless Roaming §
    Omada Mesh §
    Band Steering
    Load Balance
    Airtime Fairness
    Beamforming
    Rate Limit
    Reboot Schedule
    Wireless Schedule
    Wireless Statistics (SSID/AP/Client)

  • Wireless Security:

    Captive Portal Authentication §
    Access Control
    Wireless MAC Address Filtering
    Wireless Isolation Between Clients
    SSID to VLAN Mapping
    Rogue AP Detection
    802.1X Support
    WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

  • Transmission Power:

    CE: <20 dBm (2.4 GHz, EIRP), <23 dBm (5 GHz, Band1 & Band2, EIRP), <27 dBm (5 GHz, Band3, EIRP)
    FCC: <22 dBm (2.4 GHz), <22 dBm (5 GHz)

Management

  • Omada App: Yes
  • Centralized Management:

    Omada Hardware Controller (OC300, OC200)
    Omada Software Controller
    Omada Cloud-Based Controller

  • Cloud Access: Yes (Requires use of OC300, OC200, Cloud or Software Controller)
  • Email Alerts: Yes
  • LED ON/OFF Control: Yes
  • Management MAC Access Control: Yes
  • SNMP: v1, v2c, v3
  • System Logging: Local/Remote Syslog
  • SSH: Yes
  • Web-based Management: HTTP/HTTPS
  • L3 Management: Yes
  • Multi-site Management: Yes
  • Management VLAN: Yes
  • Zero-Touch Provisioning: Yes (Requires Cloud Controller)

Others

  • Certification: CE, FCC, RoHS
  • Package Contents:

    EAP653
    Ceiling/Wall Mounting Kits
    Installation Guide
    Note: DC adapter not included and sold separately

  • System Requirements: Microsoft Windows XP/Vista/7/8/10/11, Linux
  • Environment:

    Operating Temperature: 0–40 ℃ (32–104 ℉)
    Storage Temperature: -40–70 ℃ (-40–158 ℉)
    Operating Humidity: 10–90% RH non-condensing
    Storage Humidity: 5–90% RH non-condensing

The TP-Link Omada EAP653 is a dual-band WiFi 6 access point designed for professional environments that need reliable coverage, efficient wireless performance, and centralized network control. With AX3000-class connectivity, it is well suited for offices, hotels, schools, retail spaces, and other business locations with multiple connected devices. The EAP653 supports modern WiFi 6 capabilities that help improve network efficiency and performance in busy wireless environments. Its combination of strong throughput and business-focused wireless management makes it a practical option for video conferencing, cloud applications, everyday office traffic, and other bandwidth-demanding tasks. As part of the TP-Link Omada ecosystem, the EAP653 can be centrally managed with compatible Omada controllers. This gives network administrators a convenient way to configure, monitor, and expand wireless infrastructure across one or multiple business locations.

FAQs : TP-Link Omada EAP653

The TP-Link Omada EAP653 is an AX3000 dual-band WiFi 6 access point built for professional indoor wireless networks.
The EAP653 provides AX3000-class dual-band WiFi 6 performance, making it suitable for environments with multiple devices and demanding wireless applications.
It is suitable for offices, hotels, schools, retail environments, meeting spaces, and other indoor business networks that require dependable WiFi coverage.
You can buy the TP-Link Omada EAP653 from JRS Global Technologies Canada through jrsglcanada.com for TP-Link business networking products and solutions.
